Pixel Pitch: 2.976mm

Power Supply Mode: AC220±10% 50HZ/AC110±10%

Cabinet Size (W×H×D) ：500mm*500mm*80mm/ 500mm*1000mm*80mm

Cabinet Resolution(dot) :168*168

Brightness( adjustable ) : ≥5000cd/㎡

Pixel configuration : 1R1G1B

Module dimensions (W×H) : 250mm*250mm

Pixel density : 112896 pixels/㎡

Driving Method : 1/16scan

Gray scale per color : 256 levels of each color(RGB)

Colors : 280 trillion color

Viewing angle (H/V) : 140/120 (deg)

Working Temperature:0 Celsius- +40 Celsius

Storage Temperature:-30 Celsius- +50 Celsius

Control Mode: Synchronous dispaly with control PC by DVI

Control System: Linsn, Novastar or as your required

IP rating (Front/Rear) : For outdoor IP65/ For indoor IP20
