Pixel Pitch: 2.604mm

Cabinet Size (W×H×D) ：500mm*500mm*80mm/500mm*1000mm*80mm

Cabinet Resolution(dot) :192*192

Brightness( adjustable ) : ≥5500cd/㎡

Pixel configuration : 1R1G1B

Module dimensions (W×H) : 250mm*250mm

Pixel density : 147456 pixels/㎡

Driving Method : 1/16scan

Max Power Consumption: 1000W/sqm

Average Power Consumption: 550W/sqm

Gray Level: Red, green, blue each 256 levels

Display Color: 280 trillion color

Frame Frequency: ≥60HZ

Power Supply Mode: AC220±10% 50HZ/AC110±10%

Working Temperature:0 Celsius- +40 Celsius

Storage Temperature:-30 Celsius- +50 Celsius

Control Mode: Synchronous dispaly with control PC by DVI

Control System: Linsn, Novastar or as your required

IP rating (Front/Rear) : For outdoor IP65/ For indoor IP20
